Hinge, heavy-duty 8 40 MW-serie
Technical data
Serie: Groove 8
Typ: I
Dimensions (mm): 80 x 40 x 40
Material: ZN beschichtet
Weight: 0,320 Kg
TIN: 101813 ID: S208XG40
CAD Data
---------------
from stock
Serie: Groove 8
Typ: I
Dimensions (mm): 80 x 40 x 40
Material: ZN beschichtet
Weight: 0,320 Kg
TIN: 101813 ID: S208XG40
CAD Data
---------------
from stock
Please note
Series joints can be used for rigid or movable profile connections at any angle. The maximum swivel range is 180°. When used on the front side, an M 8 thread must be cut in the core hole of the profile. End-side connection: semi-circular screw ISO 7380,M8x25 Connection in the profile groove: semi-circular screw ISO 7380 M8x16 and Nutenstein 8 without bridge M8. Can be used with all profiles of the MW-Line series
Series joints can be used for rigid or movable profile connections at any angle. The maximum swivel range is 180°. When used on the front side, an M 8 thread must be cut in the core hole of the profile. End-side connection: semi-circular screw ISO 7380,M8x25 Connection in the profile groove: semi-circular screw ISO 7380 M8x16 and Nutenstein 8 without bridge M8. Can be used with all profiles of the MW-Line series
Here you can quickly and easily request the currently best possible price. You will immediately receive an offer including delivery time and availability. We usually have the item in stock.
starting from 9.22 €/Piece netto
request cheap unit price
⮮
⮮
