Τεχνικά δεδομένα
Σειρά: Groove 10
Typ: B
Διαστάσεις (mm): 57 x 16,75 x 11,5
Υλικό: PA, ST verzinkt
Βάρος: 0,127 Kg
TIN: 100793 ID: S210BV60K
CAD Δεδομένων
---------------
από το απόθεμα

Παρακαλώ σημειώστε
With the bolt connector set completely, stable right-angled connections of two profiles are created. In a profile, a through hole D17 with 22.5mm from the older edge must be inserted. In addition to two screws and hammer nuts, the scope of delivery includes a centering pin and two cover panels. Can be built with all profiles of the series 10 in grid 60

Από 2.29 €/Ορισμός netto
