Bolt connector set 10 40 complete


Bolt connector set 10 40 complete wie HS210BV40K
Bolt connector set 10 40 complete
Bolt connector set 10 40 complete
Technical data
Serie: Groove 10
Typ: B
Dimensions (mm): 38,4 x 16,75 x 11,5
Material: PA, ST verzinkt
Weight: 0,107 Kg
TIN: 100787
CAD Data
---------------
from stock

Please note
With the bolt connector set completely, stable right-angled connections of two profiles are created. In a profile, a through hole D17 with 22.5mm from the older edge must be inserted. In addition to two screws and hammer nuts, the scope of delivery includes a centering pin and two cover panels. Can be built with all profiles of the series 10 in grid 40

Here you can quickly and easily request the currently best possible price. You will immediately receive an offer including delivery time and availability. We usually have the item in stock.

starting from 2.09 €/Kit netto
