Technické údaje
Série: Groove 8
Typ: I
Rozměry (mm): 80 x 40 x 40
Materiál: ZN beschichtet
Hmotnost: 0,3855 Kg
TIN: 100724 ID: S208GMK40
CAD Dat
---------------
ze skladu

Upozorňujeme
Joints can be used for rigid or movable profile connections at any angle. The maximum swivel range is 180°. The clamping lever is used for easy determination of the necessary angle. When used on the front side, an M8 thread must be cut in the core hole of the profile. End-side connection: semi-circular screw ISO 7380,M8x25 Connection in the profile groove: semi-circular screw ISO 7380 M8x16 and Nutenstein 8 without bridge M8. Can be used with all profiles of the series 8 of the grid 40.

Vypnuto 10.88 €/Počítačů. netto
